IBT Specifications at a Glance
Crafted for Performance: Detailed Specifications
Material Construction
The inner tank of IBT is made up of high-grade GI sheet & it has proper insulation of high-density Polyurethane foam (PUF).
Storage Capacity
Chilled water storage ranges between 2000 ltr to 20000 ltr. It can be customized as per plant and client requirement.
Cooling Capacity
Cooling range between 0°C to 4°C, ideal for milk and perishable products. Refrigeration load ranges between 5 KW and 500 KW depending on uses and application size.
Compressor Type
Water cooled or air cooled compressors are used for efficient refrigeration. Built to support single or multiple compressors based on capacity and requirement.
Refrigerant Options
Compatible with eco-friendly refrigerants i.e. - R22 & R404.
Agitation System
High-performance agitator motor with speed controller, horse power range of 1 HP to 5 HP (depending on tank size). Ensures uniform temperature distribution.
Piping and Fittings
Material of stainless steel (SS304) or food-grade PVC for hygiene with diameter according to requirement.
Electrical Specifications
Voltage of 220V or 440V (single-phase or three-phase options). Digital display control panel with PLC & HMI for easy operation and monitoring.
Insulation Thickness
Insulation thickness between 50 mm to 150 mm of high-density Polyurethane foam (PUF) based on operational conditions and environment.
Temperature Sensors
Accuracy of ±0.5°C with multiple sensors for sensitive temperature control and monitoring.
Heat Exchanger Compatibility
Works seamlessly with plate heat exchangers (PHE) for dairy cooling.
Corrosion Resistance
All components designed to resist corrosion for long-term use. Recommended to be cleaned at regular intervals.
Drainage System
Efficient water/ice melt drainage system to prevent overflow or contamination.
Weight
The weight varies based on capacity and material used.
Compliances
Approved with various certifications like ISO, CE, and BIS standards for quality assurance.
Optional Features
Built to support battery backup or diesel generator. Scalable options to add capacity as per future requirements.
